Transport & Flotation

• Transport

  • The vertical fold design allows for lowest transport height in the industry as well as narrow transport widths
  • The 25 ft & 30 ft Precision Disk Drills also utilize a wing lock for safe transport
  • To fold or unfold the tool, a single remote lever in the tractor is used
  • While transporting or pulling in/out of a field, the ground clearance of the openers is 8.5 in
  • The wide profile of the transport wheels provide the stability to move the disk drill confidently, even at higher roading speeds
  • Maximum transport speed should not exceed 20 mph

  ​​

• Standard Flotation

  • Stubble resistant tires at all locations
  • 12 total wheels
  • Front of mainframe- 12/5L x 15 dual on castoring rigid axles
  • Front and rear of each wing --12.5L x 15 single wheel (front on caster)
  • Rear of mainframe--18L x 16.1 dual wheels on rigid axles

• High Flotation

  • Stubble resistant tires at all locations
  • 16 total wheels
  • Front of mainframe--12.5L x 15 dual on castoring walking tandem axles
  • Front and rear of each wing--12.5L x 15 duals on walking beam axles (front on castor)
  • Rear of mainframe 18L x 16.1 dual wheels on walking beam axles

Seed Distribution

• More Accurate Seed Placement

  Better stands. Better yields. Producers will achieve best-in-class emergence in a wide variety of soils and residues. Case IH Precision Disk 500 Air Drills offer the most accurate seed placement available.

• Air Packages


  Standard Air Package

  • Ideal for almost every crop and fertilizer type.
  • The primary and secondary runs feature UV resistant flexible PVC with a steel header and EZ-Flow manifold.



  Extended Wear Package

  • Ideal for highly abrasive crops like rice.
  • The primary run features 2.5 in diameter flexible PVC hoses, each with a Urethane Liner that resists wear and extends the life of the hose.
  • The secondary run is UV resistant 1 in flexible PVC hose

• Flow Monitoring Optical Sensors

  • Optional optical sensors monitor the product flow through the delivery system.
  • Quickly alert product flow concerns for quick resolution
  • Reduces skips
  • Ensures higher yields
  • When an obstruction is detected, the operator will hear an audible alarm in the cab and the blocked run will be displayed on the console
  • These sensors provide non-contact monitoring as either primary or secondary run systems for single-shoot configurations

• Split Rank Seeding

  • Row unit lock up offers the ability to easily split the front and rear ranks to allow seeding with only the front or only the rear rank.
  • Raising the ranks, then rotating either the upper (front rank) or lower (rear rank) pair of valves will prevent the rank from lowering.
  • Rank Lock-up pins whould also be inserted.
  • Stopping the seed is also required for split rank operation, a header insert kit shold be ordered to stop seed flow to the split tank.​​

• Header Stand Primary Distribution

  Standard Wear Air Package

  • The patented dimpling in the header stand allows for randomized air flow and creates even seed distribution to the EZ Flow header
  • The dimpling pattern eliminates overloading of seed to one side of the header stand

  Extended Wear Air Package

  • Includes a high wear header that prevents areas with high amounts of seed contact from wearing out
  • The header includes a reinforced area at the elbow as well as reinforced dimples to prevent the header from wearing out prematurely

• Manifold

  • EZ Flow Header is deigned for easy serviceability and accurate product distribution.
  • A replaceable steel tip on the insert reduces abration effect and prolongs life.
  • Quick access to inspect riser tube and manifold ports.

Advanced Farming Systems (AFS)

• Monitor Your Progress

  The Precision Disk 500 Disk Drill features can be managed with ease on the AFS Pro 700 monitor. Its convenient, one-page seeding display keeps all the necessary information close at hand. Case IH designed this machine to handle the needs of producers who want to be accurate, efficient and profitable​​.

• AFS Pro 700 Display

  • To simplify operation, all of the necessary screens to operate the Precision Disk 500 are all on one page-no need to change screens.
  • In-Cab Down Pressure Control (if equipped)
  • Air Cart Control​

• ISO11783 (ISOBUS)

  • Often customers desire to keep their current tractor and display. The electronic systems of the Precision Disk Drills are designed to meet that demand and are able to display:
  • In-Cab Down Pressure Control (if equipped)
  • Air Cart Control​
