Horsepower
64 - 117 HP
Transmission
Mechanical, Power or Synchronized Shuttle
Operator Environment
Cab or Non-Cab
Compatible Loaders
L565 / L575/ L620/ L630/ L103 Series Loaders

Utility Farmall C Family

Hard-Working. Heavy-Duty. Ready to Do it All.

Case IH Farmall C series tractors are hard-working, heavy-duty, deluxe tractors with flexible options to handle any application. These deluxe utility tractors feature full power, full comfort and full features and are ideal for demanding livestock duties, larger hay operations and heavy loader work.

Explore Features

Engine
Transmission Options
Operator Environment
PTO, Hydraulics & Hitches
Axles & Tires
Maintenance & Uptime
Loaders & Attachments

Hard-Working. Heavy-Duty. Ready to Do it All.

Engine

The Right Horsepower for the Job

A powerful, 4-cylinder, 3.4-L FPT engine features a quick throttle response and builds power fast. Yet, the precise metering of fuel delivered with an electronic high-pressure, common rail fuel injection system ensures efficient operation while maintaining high-horsepower levels. Six available models range from 64 to 117 horsepower (50 to 100 PTO hp).

Common Rail Direct Injection

An electronic high-pressure, common rail fuel injection system precisely meters fuel as power demands, delivering both performance and fuel efficiency. This fuel system also provides improved throttle response, fast recovery to load and quieter engine operation with less vibration.
Tier 4 B/Final Compliant

Engines use an internal Exhaust Gas Recirculation (EGR) system to meet Tier 4 B/Final requirements. A maintenance-free particulate matter catalyst provides for interruption-free operation.

Transmission

Transmission Options Suited to Your Needs

Utility Farmall C series tractors feature transmission options optimized for each model. You choose the transmission that best meets your needs and the way you plan to use your tractor. Regardless, you can rest assured the transmission you select will be easy to operate and will help you get your work done easier. Select your model and choose your transmission:

Utility Farmall 65C

12x12 (12-speed forward, 12-speed reverse) power shuttle transmission
Optional 12x12 mechanical shuttle transmission with creeper

Utility Farmall 75C (creeper available on each transmission option)

Standard 8x8 mechanical shuttle
Optional 8x8 power shuttle
Optional 12x12 power shuttle
Optional 12x12 power shuttle
Optional 12x12 mechanical shuttle

Utility Farmall 90C, 100C, 110C, 120C, choose from:

Optional 12x12 power shuttle plus synchro-shift
Optional 12x12 power shuttle plus synchro-shift with creeper
Optional 24x24 power shuttle with Hi-Lo

Easy Shifting

Move through eight power shifts by simply using the up and downshift buttons and range button on the main gear lever. Make clutchless directional changes using the momentary shuttle. Change between A/B or C/D ranges using a power clutch button. Move between B/C ranges using the foot clutch and transmission control lever.
Autoshift Option

The optional autoshift function provides many ease-of-use benefits. Simply select field or road mode and the autoshift will automatically shift between a set span of gears, based on target speed and engine load for the given operation. Although autoshift is a great option for novice operators, it also can increase the tractor’s productivity by helping to maintain a constant speed for the application.

Click to learn more

Operator Environment

Visibility, Comfort and Control Built for You

When we say you can select your comfort zone, we mean it. Cabs are standard on all six utility Farmall C models. Or choose the non-cab option knowing you’re not giving up many of the same deluxe features.

Comfort

Operators Platform: Your comfort starts with plenty of room to maneuver and nothing to get in your way. The large, flat operator area and deluxe features on cab and non-cab tractors provide outstanding comfort along with ease of operation and exceptional visibility.

Cab Comforts: Cab models offer air conditioning, along with 10 dashboard vents. Opening side windows provide fresh-air circulation. All controls and levers are within easy reach from the comfort of the operator seat.

Easy Access: Best-in-class accessibility to the driver’s seat, with two doors and self-cleaning steps on each side, help make daily chores and other work go more quickly with less operator wear and tear.

Seat Options: A redesigned operator’s seat provides exceptional comfort and productivity. Or choose the optional larger air-suspension driver’s seat with a full 15-degree pivot. Non-cab models feature a vinyl seat with armrests.
Convenience

Ergonomic Loader Joystick: To get the greatest productivity from your loader, it should be easy to operate. An ergonomic, factory-installed loader joystick integrates into the right-hand console.

Rear Sightlines: The hinged rear window opens completely and is supported by gas struts. The lower viewing window provides increased visibility to drawbar, 3-point hitch and remotes for reduced neck strain.

Easy to Use: The easy-to-read instrument cluster includes engine coolant temperature, fuel level and engine speed gauges, plus a digital speed readout on cab models. Cab models include an instrument cluster that pivots with the steering wheel. Instrument functions and positions are common with the rest of the Farmall series tractors for familiarity and ease of use.

Protection With Flexibility: A two-post roll-over protection structure (ROPS) provides protection without sacrificing visibility. The structure is foldable so you can complete tasks in low-overhead areas, and an optional sunshade canopy provides sun protection and a cooler environment on long, hot days.
Visibility

Looking Ahead: The stylish, sloped hood on all Farmall series tractors provides clear, unobstructed forward sightlines to the front wheels, loader and other front-mount attachments.

Loader Views: A curved front window frame top increases loader visibility. The optional high-visibility roof panel with opening window allows the operator to see full-range loader operation, even when the loader is extended to full height.

Instrumentation: Well-placed controls and the instrumentation dash’s design provide easy access without inhibiting visibility.

PTO, Hydraulics and Hitches

Ready for a Hard Day’s Work

The utility Farmall C series gives you the deluxe features you need at a great value. When it’s time to get to work, these tractors offer the power and flexibility — a heavy-duty 3-point hitch; high-capacity, responsive, dual-pump hydraulics; and an independent PTO — to support a full suite of implements and attachments.

Utility-Farmall-C_PTO-Hydraulics-Hitches

PTO Options
PTO configurations depend on the tractor model you choose. Standard and optional configurations include 540 rpm, 540/540E and 1,000 rpm. The 540/540E PTO option provides greater fuel efficiency during less-demanding applications.

Utility Farmall 65C and 75C
- Standard 540 rpm
- Optional 540/540E
Farmall 90C, 100C and 110C
- Standard 540 rpm
- Optional 540/540E or 540/1,000 rpm
Farmall 120C 12x12
- Standard 540/540E
- Optional 540/1,000 rpm
Farmall 120C Hi-Lo
- Standard 540/540E or 540/1,000 rpm
Hydraulics
Power With Maneuverability: Separate steering and implement hydraulic reservoirs let you lift heavy loads without sacrificing your ability to steer. The open center hydraulic system, remote valves and 3-point hitch, featuring flexible lift arms and telescopic stabilizer, make the tractors capable of handling nearly any implement.

Remotes: Utility Farmall C series tractors include two standard rear remotes. For even greater flexibility and productivity, add an optional third remote. Tractors with the factory-installed, loader-ready option feature two mid-mount remotes.

Flow Rate: Utility Farmall 65C and 75C models pump 12.5 gallons per minute (gpm); models 90C through 120C pump 16.9 gpm.

Loader Lift Capacity (maximum height at pivot pins)
- Utility Farmall C tractor paired with Case IH L565 loader: 1,940 lb (NSL) / 2,734 lb (MSL).
- Utility Farmall C tractor paired with Case IH L575 loader: 2,028 lb (NSL) 3,175 lb (MSL).
- Utility Farmall C tractor paired with Case IH L630 loader: 2,632 lb (NSL) / 3,428 lb (MSL).
Hitches
Heavy-duty 3-point: Telescopic lower links and stabilizers simplify implement attachment. A single turnbuckle levels attachments.

Hitch Lift Capacities
- Utility Farmall C65 and C75 tractors: 3,664 lb. 24 inches behind the pin
- Utility Farmall C90 through C120 tractors: 4,339 lb. 24 inches behind the pin
Extendable Drawbar: An extendable drawbar lets you customize hitched implements to your desired position or move the drawbar to keep it out of the way when not in use.

Axles and Tires

The Right Traction and Tires for the Job

Choice is good. Whether cutting, putting up or hauling hay, cleaning cattle pens or moving snow and maintaining the farmstead, utility Farmall C series tractors deliver all the power and traction you need.

2WD or 4WD

Choose the best option — depending on the traction and maneuverability your operation demands. The 2WD option is ideal for lighter field work and maximum maneuverability. Go with 4WD for improved traction and increased power to the ground.
Tire Options
- Bar tread — optimal traction for agricultural applications
- Utility tread — a longer-life option for use on hard surfaces and a smoother ride while roading
Fenders

Utility Farmall C series tractors include fenders and handles for easy entry and exit.

Maintenance and Uptime

Quicker to the Job

Utility Farmall C series tractors let you get right to the task at hand without time lost on routine maintenance. After all, the sooner you get to work, the earlier you finish.

Easy Access A single-piece hood opens without tools. Gas struts support the hood when open for quick, easy access to engine components and checkpoints. Fueling is fast and easy with fuel-tank access from the ground or from the operator platform.

Uptime Check and fill engine oil without opening the hood. A 600-hour oil-change interval reduces downtime and maximizes uptime.

Loaders and Attachments

Do More, Every Day

The utility Farmall C series gives you the versatile tractor you need at a great value. Outstanding performance and stability, along with heavy-duty frames and rugged components that are designed to be compatible with a wide range of tools and attachments, help you accomplish more, more efficiently.

Loader-ready

When you order your utility Farmall C series tractor with the complete loader-ready option, it arrives with the appropriate loader-mounting brackets, two mid-mount hydraulic valves and a front grill guard already in place. This convenience package lets you install and remove your loader in minutes.
Series Loaders

Case IH L565 / L575 / L620 / L630 / L103 loaders are designed specifically for use with your utility Farmall C series tractor. These loaders feature double-C channel arms for structural strength and streamlined appearance. Curved-boom loader arms let you easily see to the top of the bucket and around the front tires. Integrated park stands and the quick connect system improve efficiency.
Attachments

Your Case IH dealer offers a full line of attachments to help you get the most productivity from your utility Farmall C series tractor. Implements are quick and easy to hook up and include disc mowers, wheel rakes, round and square balers, rotary tillers, backhoes and many others.
Simple to Use

The factory-installed loader joystick is integrated into the right-hand console for easier operation and greater productivity.

L600 Series Loaders

Factory Installed, Ready to Work

The L600 series loaders are factory installed. They have a curved-boom loader arm, so you can easily see to the top of the bucket and around the front tires. They can be outfitted with an array of loader attachments to provide the flexibility you need for years to come.

2 Models (L620, L630)
2,478 – 3,428 lb. Max Lift Capacity
114 – 124 in. Max Height
3,739 – 5,661 lb. Breakout Force

Current Models

Utility Farmall® 65C
The Case IH utility Farmall 65C is capable of handling many chores around the farm and the ergonomically designed operator environment means you'll be comfortable doing them.
Utility Farmall® 75C
The Case IH utility Farmall 75C is an all around workhorse, yet delivers a level of operator comfort that makes long, hard days more productive.
Utility Farmall® 90C
Rugged construction coupled with reliable power makes the utility Farmall 90C a solid choice. Available in ROPS or Cab configuration.

Utility Farmall® 100C
The utility Farmall 100C is available with a factory-installed loader, it's ready to get to work.
Utility Farmall® 110C
The utility Farmall 110C was designed with input from customers in the field, it's ready for any task.
Utility Farmall® 120C
Compact and maneuverable, yet powerful enough to handle any chore, the utility Farmall 120C gets the job done.
