CYLINDERS
6
CAPACITY
6,728 cm³
RATED POWER
250 - 300 HP
MAXIMUM PUMP FLOW RATE
165 - 220 l/min

OPTIMAL EFFICIENCY

Whether its tillage, seedbed preparation, planting, or haulage during harvest, we have equipped the Optum CVXDrive with the latest systems to ensure maximum traction in the field and efficient handling and braking on the road. The Optum CVXDrive offers impressive control and safety. It feels great to drive, and we are certain you will enjoy the satisfying feeling of driving the most profitable investment around.

THE PRODUCTIVITY PROFESSIONALS

Headland Management Control II and AccuTurn Pro plus integrated ISOBUS compatibility.
Optum CVXDrive models feature Headland Management Control II, which is designed to assist the driver when turning at the headland. Each step can be programmed either by time or distance travelled. In addition, certain triggers for various other automated functions can be set, such as lowering the engine speed after lifting the implement. A headland sequence can be taken while driving or programmed on the stand. Playback of the headland sequence can be automatically or manually run. With ISOBUS III it is possible for the implement to control the Optum CVXDrive. The tractor will automatically adjust forward speed, steering (option), hitch position and PTO speed, as well as operating remote valves depending on the implement. And now, with new AFS AccuTurn Pro technology, headland management and steering processes are combined, automating the entire headland operation, calculating the optimum turning path and speed and controlling the implement, for even greater efficiency and comfort.

DESIGNED TO BE EFFICIENT

While there are no visible external changes to the Optum CVXDrive tractors, the Stage V emissions solution from Case IH engine supplier and sister firm FPT Industrial uses internal technology covered by a total of 13 different patents. With no exhaust gas recirculation, fuel consumption is minimised and combustion more efficient. As a result of the design, operating costs are kept low, the after-treatment system is maintenance-free, and reliability and uptime are maximised.
STEPLESS PRODUCTIVITY

The continuously variable transmission on Optum CVXDrive – simply the best of working. With seamless range changes between zero and top speed, integrated creeper and just 1,600 revs at 50 km/h, the CVXDrive transmission also features Active Hold Control so you can stop and start on hills without using the clutch or brakes.
A GREAT DAY AT WORK

Experience the supreme level of comfort offered by the Optum CVXDrive. Not only is it easy to use but it also looks great and is a joy to drive. The front axle provides two damping cylinders with 110 mm travel and is saddle mounted to the engine sump. An adaptive control logic is used to ensure high performance, comfort and stability.

ADVANCED TRAILER BRAKE FOR MORE SAFETY

The new Case IH Advanced Trailer Brake System represents a major advance in tractor safety and can now be specified as an option on Optum CVXDrive models. Its benefits are not confined to haulage situations on roads where conditions provide very low grip, such as snow and ice. The Advanced Trailer Brake System is also a significant advantage on wet roads and under field conditions when working on gradients, turning, or reducing speed.
OPTIMAL AUTOMATISATION

AccuTurn Pro combines the benefits of both Case IH HMC II headland management and AccuTurn automated headland steering to fully automate the headland turning process. Designed to further ease the burden on the operator and boost productivity, as well as minimising the area of trafficked headland land.
KEEP FARMING

Internal upgrades have also meant that it has been possible to extend the engine oil service interval to 750 hours, up from 600 hours. At the same time the transmission oil change interval is extended to 1,500 hours, up from 1,200 hours. For the owner, this means less time in the service bay and a reduced total cost of ownership.

See more items

SAFEGUARD WARRANTY

3 YEARS MANUFACTURER’S WARRANTY INCLUDED

Get 3 years of warranty on this product! The SAFEGUARD WARRANTY is an extension of the Base Warranty (1+2 years) to be protected from unexpected repair cost. Take advantage of our extended warranty program and work with full peace of mind.

With our extended warranty, you are sure that you are protected against additional costs. No matter if your machine is 1, 2 or 3 years old, it will be covered like at the first day.

Want more information about this program? Click here and learn more about SAFEGUARD WARRANTY.
